Gucbir Jenerator produces the generators in Turkey accordance to European Quality Standards by focusing and targeting the top quality
| Genset Brand | Gucbir Generator | |
| Genset Model | GJB1700 | |
| Standby Power | kVA | 1700 |
| Prime Power | kVA | 1500 |
| Frequency | Hz. | 50 |
| Voltage | V | 230/400 |
| Phase | 3 | |
| Fuel | Diesel | |
| Control Panel | Datakom GB500 | |
| Country of Origin | Turkey |
| Engine Brand | Baudouin | |
| Engine Model | 16M33G1700/5 | |
| Standby Power | kWm | 1530 |
| Prime Power | kWm | 1390 |
| Fuel Type | Diesel | |
| Number of Cylinders and Type | 16 At Vee | |
| Bore and Stroke | mm | 150×185 |
| Total Displacement | L | 52,3 |
| Aspiration | Turbocharged and Aftercooled | |
| Compression Ratio | 15 : 1 | |
| Rated Speed | Rpm | 1500 |
| Injection Type and System | Direct Injection | |
| Governor System | Electronic | |
| Operating Voltage | Vdc | 24 |
| Cooling System | Water Cooled | |
| Air Filter Type | Dry Type |
| Alternatör Brand | Maranello | |
| Alternatör Model | M1775 | |
| Voltage | V | 230/400 |
| Phase | 3 | |
| Frequency | Hz. | 50 |
| Power Factor | 0,8 | |
| Standby Power | kVA | 1775 |
| Prime Power | kVA | 1680 |
| Protection | IP23 | |
| Insulation | H | |
| Voltage Regulation | ±% | 1 |
| AVR Card Model | MX341 |
| Standart Specifications |
| Water cooled, Diesel engine |
| Radiator with mechanical fan |
| Protective grille for rotating and hot parts |
| Electric starter and charge Alternatör |
| Starting battery (with lead acid) including rack and cables |
| Engine coolant heater |
| Base frame design incorporates an integral fuel tank and anti-vibration isolators |
| Flexible fuel connection hoses |
| Single bearing, class H Alternatör |
| Industrial exhaust silencer and steel bellows supplied separately(for open sets) |
| Static battery charger |
| Manual for application and installation |
| Optional Equipments |
| Engine |
| • Fuel-Water Seperator Filter |
| • Low water level alarm |
| • Oil heater |
| Alternatör |
| • Anti-Condensation Heater |
| • Over sized Alternatör |
| • Main line circuit breaker |
| Control Panel |
| • Remote annunciator panel |
| • Remote relay output |
| • Alarm output relays |
| • Remote communication with modem |
| • Earth fault, single set |
| • Charge Ammeter |
| ATS |
| • Three or four pole contactor |
| • Three or four pole motor operated circuit breaker |
| Other |
| • Trailer |
| • Main Fuel Tank |
| • Automatic or manual fuel filling system |
| • Manual oil drain pump |
| • Residential silencer |
| • Enclosure: weater protective or sound attenuated |
| • Duct adapter ( on radiator) |
| • Inlet and outlet motorised louvers |
| • Inlet and outlet acoustic baffles |
| • Tool kit for maintenance |
| • Supplied with oil and coolant – 30 °C |
| • Battery isolating switch |
| Open Type | ||
| L x W x H | mm | 4600x2200x2350 |
| Weight | kg | 9922 |
| Fuel Tank Capacity | kg | 3000 |
| Silent Type | ||
| L x W x H | mm | 8000x2400x3530 |
| Weight | kg | 16120 |
| Fuel Tank Capacity | kg | 3000 |
